Name: NFR45 One Way Clutch Bearing 1500Nm Torque 1000RPM
Brand: Changzhou Suma Precision Machinery Co., Ltd
SKU: NFR45
Price: 186.00 USD
Availability: InStock

Casa Prodotti Un cuscinetto della frizione di modo

NFR45 One Way Clutch Bearing 1500Nm Torque 1000RPM

Dettagli:

Luogo di origine:	Cina
Marca:	SUMA
Numero di modello:	NFR45

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1
Prezzo:	$175-198

Contatto

Descrizione di prodotto dettagliata

Tipo:	Tipo di rullo	Valutazione di precisione:	P0
Tipo di sigilli:	Aprire	Spessore:	63 mm
Capacità di coppia:	1500Nm	Sovraccarico di gara interiore:	1000 giri / min
Sovraccarichi di gara esterni:	2400 giri al minuto	Peso:	4 kg
Dimensione del foro:	8-130mm	Dimensione della gara esterna:	37-300mm
Invadere le velocità:	1000-3600rpm	Gamma di coppia:	20-34750n.M
Gamma di spessore:	20-180mm	intervallo di peso:	0,1-68 kg
Supporto cuscinetto:	Cuscinetti in acciaio / sfera
Evidenziare:	One Way Clutch Bearing 1500Nm torque , One Way Clutch Bearing 1000RPM , NFR45 One Way Clutch Bearing

NFR45 NFR 45 One Way Backstopping Clutch Freewheel Bearings

Product Specifications

Attribute	Value
Applicable Industries	Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Construction works, Energy & Mining
Type	ROLLER TYPE
Precision Rating	P0
Seals Type	OPEN
Product Name	Backstopping Clutch Freewheel Bearings
Thickness	63mm
Torque Capacity	1500Nm
Inner Race Overruns	1000RPM
Outer Race Overruns	2400RPM
Weight	4kg

Product Description

The NFR Series One Way Backstopping Clutch is a bearing-supported roller type freewheel without any sealing. Lubrication and sealing must be provided by the installation, with standard lubrication being oil.

For sizes 8 to 20 units, steel on steel bearing supports the inner race. Above size 20, two 160...Series ball bearings are used, providing higher overrunning speed capacity.

The inner race is keyed to the shaft. The outer race has a positive n6 tolerance for a press fit in a housing to H7. Additional side notches enable positive torque transmission. The housing must be strong enough to prevent expansion after assembly.

Technical Specifications

Model	Torque (N.m)	Overrunning Speeds (rpm)	Dimension (mm)	Weight (Kg)
NFR8-NFR130	20-34750	Inner Race: 1000-250 Outer Race: 1000-3600	Bore Size: 8-130 Outer Race Size: 37-300 Thickness: 20-180	0.1-68

Detailed Parameters

1) Tmax = 2 × TKN

2) Inner race overruns

3) Outer race overruns
